This didactic procedure concerns a patient adressed from neighboring hospital for acute anterior STEMI within the first hour. The coronary angiography has shown distal left main stenosis and Proximal LAD thrombotic occlusion.
This procedure show how to deal wih crossing difficulties during primary PCI as well as management of "no reflow phenomenon".

Educational objectives

  • How to treat patients with acute STEMI.
  • Some acute thrombotic lesions may be challenging to cross.
  • How to use dedicated CTO devices during non-CTO PCI.
  • How to use thrombo-aspiration catheter to deliver adenosine distally.
  • How to treat "no reflow phenomenon" during primary PCI.
  • IVUS guidance to control stent deployment & Left main stenting during primary PCI.

Step-by-Step procedure

  • The patient has experienced repetitive cardiac arrest due to ventricular fibrillation, so he was intubated & admitted to cath-lab.
  • Right radial 6F access.
  • First coronary angiography: right system first.
  • EBU 3.5 6F guiding catheter used for the left system.
  • Left system angiography showed distal Left main significant lesion & proximal LAD thrombotic occlusion.
  • The Sion black guidewire alone has failed to cross the lesion.
  • Conventional balloon support (Rapid Exchange) has also failed to facilitate crossing the lesion.
  • Finally the lesion was crossed succesfully with Sion black guidewire & CTO dedicated microcatheter (Turnpike LP: Teleflex) support.
  • Predilatation with 2.0x20mm balloon has been performed.
  • First stent implantation: Xience Sierra 3.0x28mm (Abbott) in the proximal-Mid LAD inflated at 12ATM.
  • The angiographic control revealed LAD "non reflow ".
  • Thrombo-aspiration cathter Export 6F (Medtronic) was used to deliver distally repetitive Adenosine Bolus.
  • The angiographic control with Tip injection through the Export catheter showed sgnificant flow improvement.
  • Second short stent  Xience Sierra  2.75x8mm(Abbott)  was implanted to cover distal edge dissection.
  • IVUS was used to control LAD stents deployment & assessment of the distal Left main stenosis.
  • Third Xience Sierra (abbott) 4.0x28mm was implanted on the left main to the Proximal LAD with some plaque shift to the Left circumflexe artery.
  • POT was performed with a 5.0x8mm balloon, the patient has experienced again a Ventricular fibrillation during balloon infation.
  • The final angiographic & hemodynamic results were satisfactory.

Protocol

  • Contrast medium: Optiray 350 (Guerbet): 179ml.
  • Prcedural time: 60min.
  • Exposure time: 19min.
  • Exposure: 2399mGy.
